Height:5U/9U
Input Voltage: 220VAC/380VAC.
AC Distribution: 32A/1p*3PCS.
Output Voltage: 43~58V DC, default: 53.5V DC.
Rectification Module（50A）: R4850*6~8PCS (optional configuration).
DC Distribution: LLVD-63A*6 (optional configuration).
DC Distribution: BLVD-125A*3, 63A*6 (optional configuration).
Battery Distribution: 125A*4PCS (optional configuration).
AC Lightning Protection: 20/40KA.
Electricity Measurement: Five-way users.
Monitoring Module: Self-developed HMU48A*1PCS.
Local Display: 128*48 point line LCD.
Communication Interface: North RS485 serial port*1.
Communication Interface: South RS485 serial ports*2.
Environmental Monitoring: TMP/HS/smoke/Magnet sensor/water immersion.
